Stanley Stud Sensors
  • The TLM330 is the advanced professional LDM, accurately measuring up to 330 feet, about the length of a football field. This unit has a multitude of features including 3 different Pythagoras functions, triangular area calculation, min/max distance tracking, and a stake-out function to accurately measure the same length repeatedly. The TLM330 even features an inclination sensor that allows the unit to be used as a digital level/angle finder.

    1. Range 330' (100m) / Accuracy +/- 1/32" (1mm)
    2. Measures Distance, Calculates Area & Volume
      Automatic calculations make job estimates quick & easy
    3. Continuous Measurement
      Finds distance from target quickly & easily
    4. Inclination sensor
      Integrated digital leveling feature for leveling surfaces and identifying angles and position for accurate measurements
    5. Indirect measurement using Pythagoras
      Measure distances even when point A and/or point B isn’t accessible for linear measurement
    6. Memory
      Unit stores last 20 measurements taken for reference
    7. Backlit, 3 Line Display
      Large LCD provides visibility in all working conditions
    8. Multifunctional end piece
      Folding end piece makes true corner-to-corner measurements easy and accurate
    9. See chart below for additional features/capabilities
    TLM330
  • The TLM165 is created for advanced DIYer's or professionals and can measure up to 165 feet, has a memory function to store your previous five measurements, and has Pythagoras functions. The Pythagoras tool is a real problem-solver because it helps calculate indirect height measurements by calculating the third side of a triangle. As a result, you can measure from where you are standing to the top of the height you want to measure, and then to the bottom, once you have those measurements, the Pythagoras function will calculate the height distance between those two points.

    1. Range 165' (50m) / Accuracy +/- 1/16" (1.5mm)
      Pythagoras

      Pythagoras

    2. Measures Distance, Calculates Area & Volume
      Automatic calculations make job estimates quick & easy
    3. Continuous Measurement
      Finds distance from target quickly & easily
    4. Indirect Measurement using Pythagoras
      Measures height even when point A and/or point B is not accessible for linear measurement
    5. Memory
      Unit stores last 5 measurements taken for reference
    6. Backlit, 2 Line Display
      Provides visibility in all working conditions
    7. Corner Stand-Off
      End post makes true corner-to-corner measurements easy & accurate
    8. Over-Molded Housing and Water/Debris Resistant
      For durability & protection
    9. See chart below for additional features/capabilities
    TLM165
  • The TLM99 makes home improvement projects and job estimations simple, and is the right fit for DIYers and tradesmen. This easy to use and accurate tool can calculate area for painting and flooring material estimations, take linear measurements for a fence or interior trim, or find the cubic footage of a space.

    1. Range 100' (30m)
      Calculates Area/Volume

      Calculates Area/Volume

    2. Accuracy +/- 3/32" (2mm)
    3. Measures Distance, Calculates Area & Volume
      Automatic calculations make job estimates quick & easy
    4. Continuous Measurement Tracking Function
      Finds distance from a target quickly and easily
    5. Addition/Subtraction
      Convenient way to calculate in
    6. See chart below for additional features/capabilities
    TLM99

    Stanley’s team of world-class engineers and industrial designers has developed a series of versatile electronic tools that deliver an unprecedented level of accuracy, reliability and long-term performance. The lineup includes three different laser distance measurers. These handheld, battery-powered devices feature state-of-the-art electronics and easy read LCD screens that make the process of taking long measurements or performing complex calculations fast and easy. The range of Stanley Laser Distance Measurers is designed to accelerate both the estimating and execution of jobs for a wide range of people, making them more productive. People like:

    1. Builders and remodelers
    2. Tradesmen, like drywallers, painters, flooring installers
    3. Inspectors, appraisers, realtors, architects
    4. Homeowners/DIYers

    Regardless of the application, Stanley’s LDMs are a perfect addition to any tool box.

PERFORMANCE / FUNCTIONS STHT77138
TLM99
STHT77139
TLM165
STHT77140
TLM330
Range 4" – 100'
(10cm – 30m)
4" – 165'
(10cm – 50m)
2" – 330'
(5cm – 100m)
Accuracy ± 3/32"
(2mm)
± 1/16"
(1.5mm)
± 1/32"
(1mm)
Distance / Area / Volume
Continuous Measurement
Calculator Plus / Minus
Historical Memory / Recall 5 20
Pythagoras Functions 2 3
Height Tracking / Indirect Horizontal Distance
Inclination Sensor
Min / Max Tracking
Triangular Area
Digital Level
Stake Out
FEATURES
Measuring Units ft / in / m ft / in / m ft / in / m
Display Backlight
Audible Beep
Flip-out End piece
Timer
Quick-start Guide
CD ROM Instruction Manual
1/4" Thread for Tripod Mounting
