77-920 - TLM 200 Professional FatMax™ Tru-Laser™ Distance Measurer
Print Printer Friendly Version  Email to a friend
Click to Enlarge
FatMax™ Tru-Laser™
Click to Enlarge
Features and Benefits
  • ”Tru” laser measuring for the Professional– When it has to be accurate. Just point the laser, press the button, and measure
  • Ideal for: Appraisers, Carpenters, Plumbers, Technicians, Floor and Tile Layers, and Painters.
  • Versatile– Measure indoors, outdoors, and hard to reach areas.

  • Tru Laser technology– actually measuring the laser light travel distance
  • Large clear LCD graphical display
  • Single Point and Push ON/Measurement
  • Impact resistance housing with ergonomic grip for comfort
  • Measure areas, volumes, single distance, as well as calculate- add / subtract
    Accuracy: ± 1/8" (± 3mm) at 100-ft (30m)
    Range: 1'-100' (0.3m - 30m)
    Laser: 650 nm, Class 2M
    Pythagoras: Simple, 2-Point
    Tracking: min./max. distance
    Display Size: 35mm x 35mm, 290 Segments, backlight
    Units of Measure: FT/1/8”, FT/100ths, IN/10ths, Metric
    Splash and dust proof: IP54
    Indicators: Low Battery, Message Codes, Measurement reference (front / rear), and more
    Batteries: 2- ‘AAA’ 1.5V

Product Details
DANGER: Laser Radiation - Avoid direct eye exposure
Max output power: 5mW @ 635-760 nm
Class IIIa Laser Product
