| FatMax™ Tru-Laser™ |
 |
|
|
|
|
| Features and Benefits |
- ”Tru” laser measuring at the press of a button–
Just point the laser, press the button, and measure. One person measuring, saving both time and money.
- Ideal for: Appraisers, Carpenters, Plumbers, Technicians, Floor and Tile Layers, and Painters.
- Versatile– Measure indoors, outdoors, and hard to reach areas.
- Tru Laser technology– actually measuring the laser light travel distance
- Larger LCD graphical display
- Single Point and Push ON/Measurement
- Ergonomic rubberized grip for comfort and impact resistance
- Measure areas, volumes, single distance, as well as calculate- add / subtract
Accuracy: ± 1/4" (± 6mm) at 100-ft (30m)
Range: 2'-100' (0.6m - 30m)
Laser: 650 nm, Class IIIA
Display Size: 2-line
Units of Measure: FT/1/8”, FT/100ths, IN/10ths, Metric
Splash and dust proof: Low
Indicators: Low Battery, Message Codes, Measurement reference (front / rear), and more
Batteries: 9V (included)
| Compare Ultra Sonic vs. Tru Laser™ Distance measurement |
| Function |
Laser |
Ultra Sonic |
| Measurement |
2'-100' |
2'-50' |
| Resolution |
0.04" |
0.40" |
| Accuracy at 100' |
± ¼" |
± 4" |
| Measurement Spot Size at 50' |
0.6" |
106" (8.9') |
| Influence of atmosphere temperature (10m dT=10°C) uncompensated |
± 0.004" |
± 7" |
| Influence of Humidity 50%...90% |
<0.004" |
1.1" |
|
|
|
|
| Height |
11",279.4mm |
| Length |
8",203.2mm |
| Width |
2",50.8mm |
| Weight |
1 lbs, 0.45 kilos |
|
| Application |
- Appraising
- Carpentry and Framing
- Floor and Tile Layout
- Window Measuring
- Plumbing
- Painting
- Interior Design planning
|
|
|
|
|
